Low Voltage distribution panel
SOLAR CELL CONTROL PANEL is an intelligent control center specifically designed for solar power generation systems, integrating functions such as PV inverter, DC distribution, AC distribution, and monitoring system. This product provides efficient, safe, and reliable power conversion and system control for solar power plants, suitable for various photovoltaic power generation projects, maximizing solar energy utilization.
Detailed Technical Specifications
Parameter Category | Technical Specifications |
System Parameters | DC Input Voltage: 600V-1500V DC |
Protection Degree | IP54 (Outdoor standard), IP65 (High protection level) |
Enclosure Material | 1.5-2.5mm galvanized steel or 304 stainless steel |
Environmental Conditions | Operating Temperature: -25℃～+60℃ |
Communication Interfaces | RS485, Ethernet, WiFi, 4G |
Safety Certifications | IEC 62109, IEC 62477, UL 1741 |
Key Product Features
1.High Efficiency Energy Conversion
MPPT technology: Maximum Power Point Tracking, improving power generation efficiency
Dual MPPT: Support dual string input, reducing shading impact
Wide voltage range: Adapt to different lighting conditions
Low standby power consumption: ＜1W, energy saving and environmental protection
2.Intelligent Monitoring System
Real-time data: Power generation, voltage, current, power monitoring
Fault alarm: Real-time fault detection and alarm
Remote control: Support remote start/stop and parameter setting
Data recording: Power generation data storage and analysis
3.Comprehensive Protection Functions
DC protection: Reverse connection, overvoltage, undervoltage protection
AC protection: Overcurrent, overload, short-circuit protection
Insulation monitoring: DC side insulation resistance monitoring
Lightning protection: AC/DC side surge protection
4.User-friendly Design
LCD display: Color touchscreen, real-time data display
Multilingual interface: Support Chinese/English switching
Easy installation: Modular design, easy installation and maintenance
Expansion interfaces: Support function expansion and upgrade
5.Grid Adaptation Functions
Grid connection certification: Complies with various grid requirements
Power regulation: Adjustable active/reactive power
Low voltage ride-through: Support continuous operation during grid faults
Anti-islanding protection: Ensure grid safety
Typical Applications
Residential PV: Residential rooftop PV systems
Commercial PV: Factory, shopping mall rooftop power stations
Large-scale power plants: Ground PV power plants, fishing and solar complementary
Off-grid systems: Independent power supply systems in non-electrified areas
Energy storage systems: Integrated solar-storage solutions
Special applications: BIPV, solar carports, etc.
Optional Configurations
Residential type: 3-10kW, single-phase output
Commercial type: 10-100kW, three-phase output
Power plant type: Above 100kW, centralized solution
Energy storage type: Equipped with battery management system
Smart type: Support smart grid functions
