MG Motor Soft Start Cabinet

MG digital soft starter is a high-tech product designed and manufactured by our company specially for users. It is simple in structure, easy to use, safe and reliable, full-featured, low starting current, small in size, energy-saving and high in life. It can overcome the defects of traditional Y-△starting, autotransformer starting, resistance buck starting. Such as high inrush current, torque impact. It overcomes the shortcomings of bulky size, complicated line, high energy consumption, high maintenance rate,etc.It is an ideal replacement product of traditional starter.

Next Product Inquire Now

Model Number and Meaning

Motor power

Voltage level

Cabinet construction

Soft starter

Main Technical Parameters

Model number	Power (kW)	Rated current (A)	Overall Dimension(mm)						Weight (Kg)
Model number	Power (kW)	Rated current (A)	A	B	C	D	E	F	Weight (Kg)
MG-15-30	15,17,22,30	32,37,54,75	1000	500	350	35	250	440
MG-37-75	37,45,55,75	86,97,130,155	1400	600	430	35	345	390
MG-90	90	180	1600	660	530	35	440	500	90
MG-110	110	220	1600	660	530	35	440	500	90
MG-132	132	260	1600	660	530	35	440	500	120
MG-160	160	318	1600	660	530	35	440	500	120
MG-225	225	460	1600	660	530	35	440	500	145
MG-250	250	490	1800	660	530	35	500	450	145
MG-320	320	630	1800	660	530	35	500	450	170
MG-400	400	790	2000	800	600	35	400	610	200
MG-500	500	980	2000	800	600	35	400	610	200
MG-600	600	1100	2000	800	600	35	400	610	200
MG-810	810	1400	2000	800	600	35	400	610	200
