Low Voltage Switchgear & Distribution Panels
METER PANEL is an intelligent power distribution solution specifically designed for energy metering, power monitoring, and energy consumption management. This product integrates high-precision energy metering devices, protection equipment, and communication modules, providing accurate metering, real-time monitoring, and data analysis functions. It is suitable for commercial buildings, industrial facilities, and utilities that require precise measurement and management of electricity usage.
Detailed Technical Specifications
Parameter Category | Technical Specifications |
Rated Characteristics | Rated Current: 100A, 250A, 400A, 630A, 800A |
Metering Accuracy | Energy Measurement Accuracy: Class 0.5S, Class 1.0 |
Protection Degree | IP41 (Indoor standard), IP54 (High protection level) |
Enclosure Material | 1.5-2.0mm premium cold-rolled steel |
Enclosure Dimensions | 800×600×250mm to 1200×800×300mm |
Display Features | LCD display |
Communication Interfaces | RS485 communication (Modbus-RTU protocol) |
Compliance Standards | IEC 62052-11, IEC 62053-21, IEC 61557-12, GB/T 17215 |
Key Product Features
1.High-precision Metering Function
Multi-function energy meter integration, supporting active/reactive energy measurement
Bidirectional energy metering, supporting distributed energy sources like PV systems
Multi-tariff billing function, supporting peak/valley electricity pricing
Data recording function, recording maximum demand, load profiles, etc.
2.Intelligent Monitoring System
Real-time monitoring of electrical parameters: Voltage, Current, Power, Power Factor
Limit alarm function, setting alarm thresholds for parameter abnormalities
Event recording function, recording power outage, phase loss, reverse phase events
Remote control function, supporting remote switching operations
3.Communication and Data Management
Multiple communication methods: Wired RS485, Ethernet, Wireless communication
Standard communication protocols: Modbus, DL/T645, IEC 61850
Data upload function, supporting integration with energy management systems
Web server function, supporting direct browser access
4.Safe and Reliable Design
Dedicated metering compartment with seal design for anti-tampering
Independent protection system with overvoltage and overcurrent protection
Lightning protection device, preventing damage from lightning strikes
Insulation monitoring function, ensuring electrical safety
5.Easy Installation and Maintenance
Modular design for easy installation and maintenance
Front wiring design for convenient cabling construction
Transparent viewing window for easy meter reading
High expandability supporting future function upgrades
Typical Applications
Commercial Buildings: Office buildings, shopping malls, hotel energy management
Industrial Facilities: Factory workshops, production line energy monitoring
Public Utilities: Schools, hospitals, government building electricity management
Residential Complexes: Centralized metering for residential electricity usage
Infrastructure: Data centers, communication base station power monitoring
New Energy Field: Photovoltaic power stations, charging station energy metering
Optional Configurations
Basic Type: Single energy metering function
Standard Type: Metering + basic monitoring functions
Intelligent Type: Full-function metering monitoring + communication functions
Custom Type: Customized development based on special requirements
Q1: What materials are your Meter Panels made of, and are they suitable for extreme outdoor environments?
A: We offer a variety of high-performance materials tailored to your project environment. For severe outdoor conditions, we highly recommend our SMC (Sheet Molding Compound) / Fiberglass or UV-stabilized Polycarbonate (PC) enclosures. These materials provide excellent UV resistance, flame retardancy (V0 grade), and are completely rust-proof, making them ideal for coastal, high-temperature, or humid areas. We also manufacture standard Cold Rolled Steel or Stainless Steel panels for indoor or specific industrial uses.
Q2: What are the IP and IK protection ratings of your outdoor meter boxes?
A: Our outdoor meter panels are rigorously designed to withstand harsh weather and physical impact. Typically, they feature an ingress protection rating of IP54 to IP65 (dust-tight and protected against water jets) and an impact resistance rating of IK08 to IK10 to prevent vandalism and accidental damage.
Q3: Do the enclosures feature transparent viewing windows for easy meter reading?
A: Yes, our meter panels are equipped with high-clarity, UV-resistant polycarbonate viewing windows. This allows utility personnel or consumers to easily read the meter display and check the status of internal circuit breakers without opening the enclosure, enhancing safety and convenience.
Q4: How do your meter panels prevent electricity theft and unauthorized access (Anti-tampering)?
A: Security is a critical design feature. Our meter boards come with multiple anti-tampering mechanisms, including concealed hinges, specialized triangular or custom-key locks, and provisions for utility company security lead seals. The design ensures that any attempt to force open the box will leave visible evidence.
Q5: Can your meter panels comply with our local power utility / national grid standards?
A: Yes. We have extensive experience manufacturing meter panels that meet various international utility specifications (such as IEC standards). As a direct manufacturer, we can fully customize the dimensions, internal layouts, busbar dimensions, and wiring colors to strictly comply with the regulations of your local power authority or national grid.
Q6: What types of energy meters can your panels accommodate?
A: Our customized panels are highly versatile. They can be engineered to accommodate single-phase meters, three-phase meters, DIN-rail mounted smart meters, standard BS (British Standard) footprint meters, and prepaid keypad meters. We can supply single-meter boxes up to multi-meter cabinets (e.g., 2-way to 24-way or more) for apartment complexes.
Q7: Can you provide fully pre-wired meter panels to save installation time on-site?
A: Absolutely. To significantly reduce your on-site labor costs, our factory can deliver pre-wired solutions. We can pre-install the required miniature circuit breakers (MCBs), molded case circuit breakers (MCCBs), copper busbars, neutral/earth terminal blocks, and all internal wiring according to your provided electrical schematics.
Q8: We are bidding on a government tender. Can you open new molds (tooling) for a specific meter box design?
A: Yes. Since we own our manufacturing facilities, we strongly support clients bidding on government or utility tenders. If the tender requires a unique enclosure shape or specific structural features, our engineering team can provide OEM/ODM services, including 3D drawing, rapid prototyping, and opening new injection or SMC molds.
Q9: What is your production capacity and lead time for large bulk orders of meter boxes?
A: We are well-equipped for high-volume production. For standard designs, our lead time is typically 2 to 4 weeks. For massive tender orders (e.g., tens of thousands of units), we can establish a dedicated production schedule and arrange partial shipments to ensure you meet your project deadlines without delay.
Q10: Since plastic or SMC meter boxes can be bulky, how do you optimize packaging for ocean freight?
A: We deeply understand the impact of shipping volume on your total cost. Where structurally possible, we offer "nestable" box designs to save container space. For fully assembled panels, we use high-strength corrugated cartons reinforced with corner protectors, and stack them on fumigation-free pallets wrapped in protective stretch film to ensure zero transit damage.
